Double steel door with colour range icon

Double Steel Door (Security)

From £599.99 inc. VAT (£499.99 + VAT)

Our Double Steel Doors feature our trademark multi point locking system and are available in stock from 1295mm right up to 2195mm wide (external frame size). For sizes 1295mm & 1395mm wide we offer our leaf & a half doors; which are a ‘door and a half’; introduced to bridge the gap between our single and double steel doors.

Our Ultra Steel Double Door Range features thicker gauge steel, higher security locks and improved insulation values for an all round higher security double personnel door.

  • Total

SKU: DDP-DOOR-1 Category: GTIN: 5060479950362

Sizing your Door

Our Double Steel Doors are available from 1295mm right up to 2195mm and feature our trademark multipoint locking system. Also available as Leaf and a Half Doors to bridge the gap between our single and double doors.

Security Steel Doors

Featuring a 10 point locking system plus 4 dog bolts and latch, a total of 15 points secure the active door leaf in the frame. The passive door leaf features a concealed flush bolt to the top and bottom.

Customise your Personnel Door

Supplied as standard powder coated in Latham’s Stock White, we also offer a powder coating service so you can match your steel door and frame to your building and surroundings.

DDA Compliant Steel Doors

This personnel door is great for disabled access as it complies with the Disability Discrimination Act by having a level threshold with a maximum upstand of 12mm with chamfered edges.

Versatile Steel Entry Doors

Latham’s steel doors offer a great deal of versatility and can be used for a variety of applications within your business or your home. All of our steel security doors are fitted with weather and draught proof seals as standard and are customisable with a range of accessories.

Door Type

Personnel

Available Sizes (mm)

1295×2020, 1395×2020,1495×2020, 1595×2020, 1695×2020, 1795×2020, 1895×2020, 1995×2020, 2095×2020, 2195×2020

Finish

White powder coat from stock, choice of colours available

Design

Plain door with flush panel

Door Frame Material

1.8mm Galvanised Steel

Door Frame Depth

90mm

Door Leaf Material

Double skinned 1.0mm galvanised steel

Door Leaf Depth

50mm

Door Leaf Core

Mineral wool insulation

Internal Strengthening

2 x horizontal & 1 x vertical reinforced bars per door leaf

U Value

2.20

Acoustic Value

35dB

Hinges

8 Stainless steel ball bearing hinges

Handles

Hooply handles (5586)

Locks or Door Furniture

Active leaf: 10 point locking system | Passive leaf: Flush bolts top and bottom

Cylinder

UAP Tradelock Euro Cylinder, security upgrade available

Seal

Nylon self adhesive V-seal

Dog Bolts

4 Dog bolts on each door leaf (8 in total)

Threshold

DDA (Disability Discrimination Act) compliant threshold

Jemmy Bar Lip

At door jam, hinge side & top + astragal

Construction

Fully welded construction

Security Type

Medium

CE Certification

Yes

Security Certification

None

Fire Rating Certification

None

Stock Product

Yes

Made to Measure Product

No

Internal or External Use

Suitable for external and internal use

Example Door Purposes

Double garage door, rear shop door, loading bay door, warehouse double door, office security door

Videos


FAQs

How do I choose the hinge side and opening? (Handing)

Hinge side and opening is always determined viewed from outside. The active leaf (the door which opens first) can be determined as follows:

Example 1: LH active leaf opening out. The handle is on the left door and you would pull the door towards you.
Example 2: RH active leaf opening in: handle is on the door to the right-hand side and you push the door away from you.

See our handy illustration here

How do double doors get delivered?

Your steel double door will be delivered in a minimum of 4 boxes:

2 x door leaves packaged individually
1 x box containing the hinge posts
1 x box containing the head of the frame and the bottom threshold

By delivering your steel double door frame in self-assembly pieces, it reduces the amount of handling of the doors. This in turn reduces associated health and safety risks as the door and frame are delivered in separate, manageable boxes meaning they’re less likely to be dropped causing unnecessary damage to the door.

Please note, delivery is kerbside only. We request that another party is present to help unload.

How do I put together a double door knockdown frame?

For specific advice regarding building the self-assembly knockdown frame for your steel double door, see our blog post

What is the lead time?

Stock Door (white, no modifications) – in stock – 0 days
Stock Door (white, modified e.g. installed accessories, vision panel e.t.c) – 4 working days
Re-Powder Coated Stock Door, with or without accessories installed (not white) – 10 working days
Fast track options are also available

How many keys come with the door?

Personnel doors come with 5 usable keys. Upgraded cylinders come with 3 keys.
Additional keys are available – we have a key cutting machine on-site
See our cylinder options video here

How much do the steel doors weigh?

Double doors weigh on average 110kg*
*size dependant

What are the door sizes? What is the clear opening?

The sizes listed are external frame sizes.
We offer side panels and over panels if you need to add to the width or height of the door. We also offer a cut down service to reduce the height of the door
To calculate the clear opening (when the door is open), subtract 110mm from the width dimension. E.G. 895mm-110mm=760mm clear opening
See the video on how to measure here

What is Security Trim?

The security trim kit fits around the perimeter of the door frame, preventing any packing from being seen externally and making the door as a whole more secure.
It hides un-level or large gaps, hides the position of fixings eliminating the risk of tampering from intruders and crucially protects the fixings from attack.
See the security trim video here

To see all FAQs, click here

Downloads

Operation & Maintenance Manual

Download operation & maintenance manual
